GPRS High Accuracy Ultrasonic Oil Flow Meter

Ask Lasest Price
Brand Name :	Lanry
Model Number :	TF1100-EI
Certification :	CE
Price :	Negotiable
Supply Ability :	100unit/week

Add to Cart

Product Details
Company Profile

GPRS High Accuracy Ultrasonic Oil Flow Meter

Easy to use high accuracy ultrasonic flow meter TF1100-EI for oil measurement

Our high accuracy ultrasonic flow meter TF1100-EI for oil measurement has been proven that it is reliable and absolute matured achievement in high accuracy measurement.

ultrasonic flow meter TF1100-EI provides abundant capabilities for accurate liquid flow measurement from outside of a pipe. It utilizes state-of-the-art technologies on ultrasonic transmission /receiving, digital signal processing and transit-time measurement. The proprietary signal quality tracking and self-adapting technologies allow system to optimally adapt to different pipe materials automatically. Due to hot-tapped mounting of insertion transducers, there is no ultrasonic compound and coupling problem; Even though the transducers are inserted into pipe wall, they do not intrude into the flow, thus, do not generate disturbance or pressure drop to the flow. The insertion (wetted) type has the advantage of long-term stability and better accuracy.

Easy to use high accuracy ultrasonic flow meter TF1100-EI for oil measurement Features:

1. Thermal energy measurement capability can be optional.
2. For commonly used pipe materials and diameters from 20mm to over 6.0m.

3. Wide bi-directional flow range of 0.01 m/s to 12 m/s..

4. Hot-tapped installation, no pipe line flow interrupted
5. Wide liquid temperature range: -35℃~200℃.
6. Data logger function for insertion ultrasonic flow meter

Application

General
● Service and maintenance

● Replacement of defective devices

● Performance and efficiency measurement
- Evaluation and assessments
- Capacity measurement of pumps
- Monitoring of regulating valves

● Energy efficiency audits

Water and waste water industry - hot water, cooling water, potable water, sea water etc.)
Petrochemical industry
Power supply- nuclear power plants, thermal & hydropower plants), heat energy boiler feed water.etc
Metallurgy and mining applications
Mechanical engineering and plant engineering-pipeline leak detection, inspection, tracking and collection.

GPRS High Accuracy Ultrasonic Oil Flow Meter

Specifications:Transmitter

Measurement principle	Ultrasonic transit-time difference correlation principle
Flow velocity range	0.01 to 12 m/s, bi-directional
Resolution	0.25mm/s
Repeatability	0.2% of reading
Accuracy	±1.0% of reading at rates >0.3 m/s);±0.003 m/s of reading at rates<0.3 m/s
Response time	0.5s
Sensitivity	0.003m/s
Damping of displayed value	0-99s(selectable by user)
Liquid Types Supported	both clean and somewhat dirty liquids with turbidity <10000 ppm
Power Supply	AC: 85-265V DC: 24V/500mA
Enclosure type	Wall-mounted
Degree of protection	IP66 according to EN60529
Operating temperature	-20℃ to +60℃
Housing material	Fiberglass
Totalized	gallons, ft³, barrels, lbs, liters, m³,kg
Thermal energy	unit GJ,KWh can be optional
Communication	4~20mA(accuracy 0.1%),Frequency(1-9999Hz), Relay, RS232, RS485 (Modbus),Logged data
Security	Keypad lockout, system lockout
Size	244196144mm
Weight	2.4kg

Specifications:Transducer

Degree of protection	IP67 or IP68 according to EN60529
Suited Liquid Temperature	Std. Temp.: -35℃~85℃
Suited Liquid Temperature	High Temp.: -35℃~150℃
Pipe diameter range	DN65-6000
Transducer Size	Type S Φ58*199mm
Material of transducer	Stainless Steel
Cable Length	Std: 10m
Temperature Sensor	Pt1000, 0 to 200℃, Clamp-on and Insertion type Accuracy: ±0.1%

Datasheet Download TF1100-EI transit-time insertion ultrasonic flowm...

Manual Download TF-1100-EC&EI heat meter Manual.pdf

Packing & Delivery

Inserted Type Ultrasonic Flow Meter With 4-20mA Output for clean liquid application

With years of export experience along with excellent quality, advanced services and competitive prices, Lanry has won numerous customers' trust and support. With years of export experience along with excellent quality, advanced services and competitive prices, Lanry has won numerous customers' trust and support.

Delivery

Inserted Type Ultrasonic Flow Meter With 4-20mA Output

Standard meter: 3-7 days

Special meter: pls contact us

Express, by air, by sea can be optional.
