    IP68 Area Velocity Flow Meter High Precision 16GB Data Logger With GPRS Output

    Ask Lasest Price
    Brand Name : LANRY
    Model Number : DOF6000-W
    Certification : CE
    Price : Negotiable
    Supply Ability : 100pcs /week
    • Product Details
    • Company Profile

    IP68 Area Velocity Flow Meter High Precision 16GB Data Logger With GPRS Output

    Doppler open Channel Ultrasonic Flow meter DOF6000-W with GPRS output
    Our high precision Doppler open Channel Ultrasonic Flow meter DOF6000-W Widely used in sewage plants, sewage outfall of enterprises and institutions, city sewer flows and irrigation Channels and so on. DOF6000 series DOF6000 Digital River Water Flow Meter consists of flow calculator, and the integrated DOF6526 transducer to measure velocity and level at the same time.
    Ultrasonic Flow meter also can be available with 4-20mA, RS232, RS485 (Modbus) /GPRS and SD
    card logger outputs.
    Doppler open Channel Ultrasonic Flow meter DOF6000-W with GPRS output Features:

    1. Measure flow in partially filled pipes and open channels.
    2. 16GB SD card data logger can be optional.
    3. Display the velocity, level, flow rate and flow totalizer.
    4. No flume or weir required.
    5. 20 coordinate points to describe the river’s shape of cross section.
    6. 4-20mA, RS485 (Modbus) /GPRS outputs are available.

    Doppler open Channel Ultrasonic Flow meter DOF6000-W with GPRS output Specifications:
    Calculator:
    Enclosure typeWall-Mounted
    Power Supply:85~265VAC,12~28 VDC(Wall-mounted)
    Degree of protectionIP65
    Operating temperature-20℃ to +60℃
    Application rangePipe: 300-6000mm, Channel: 200-6000mm
    Outputs:4-20mA, RS485(Modbus), data logger, GPRS (optional)
    Enclosure MaterialFiberglass(Wall-mounted)
    Size244L×196W×114H (mm)
    Data logger16GB
    Weight2.4kg

    Specifications :DOF6526 sensor

    DOF6526 sensor:

    Depth

    Range:

    0m to 3.0m or 0m to 6.0m


    Accuracy:

    ±0.25% of calibrated lower range


    Resolution:

    H2 0-1m at 1mm, 1-2m at 2mm
    H5 0-2.5m at 2.5mm, 2.5-5m at 5mm

    Velocity

    Range:

    21mm/s to 4500mm/s bi-directional


    Accuracy:

    2% of measured velocity


    Resolution

    1mm/s

    Temperature

    Temperature:

    -17°C to 60°C


    Resolution:

    0.1°C

    General

    Cable:

    15M


    Cable Options:

    User specified up to 100 meters


    Material:

    PVC body, stainless steel mounting plate


    Dimensions:

    290mm x 70mm x 30mm (L x W x H)

    FlowComputation:0.1°C
    Channel type:Flow rate, flow totalizer
    IP68 Area Velocity Flow Meter High Precision 16GB Data Logger With GPRS Output
    Installation details:
    IP68 Area Velocity Flow Meter High Precision 16GB Data Logger With GPRS Output
    Packing & Delivery

    Packing

    Wall-Mounted Doppler type Ultrasonic Flowmeter DOF6000-W 200-6000mm for Open Channel Application
    With years of export experience along with excellent quality, advanced services and competitive
    prices, Lanry has won numerous customers' trust and support.With years of export experience
    along with excellent quality, advanced services and competitive prices, Lanry has won
    numerous customers' trust and support.

    IP68 Area Velocity Flow Meter High Precision 16GB Data Logger With GPRS OutputIP68 Area Velocity Flow Meter High Precision 16GB Data Logger With GPRS Output

    Delivery
    Standard meter: 3-7 days
    Special meter: pls feel free to contact us
    Express, by air, by sea can be optional.
