    Bi - Directional Ultrasonic Hot Water Flow Meter With RS485 Steady Operation

    Ask Lasest Price
    Brand Name : Lanry
    Model Number : RC82
    Certification : CE
    Price : Negotiable
    Supply Ability : 2000 Unit/Units per Day DN15-40 mm Bi-directional Energy Meter Price
    • Product Details
    • Company Profile

    Bi - Directional Ultrasonic Hot Water Flow Meter With RS485 Steady Operation

    Wireless Digital Energy Meter with RS485 digital heat meter RC82 ultrasonic heating
    Wireless digital heat meter RC82 has been proven that it is reliable and absolute matured achievement in high accuracy measurement.
    RC82 Series ultrasonic heating (cooling, heating-cooling) meters are used for energy measurement of heating or chilled water in residential and small commercial heating and air conditioning systems. They are available in DN15…40 and have an electronic energy calculator with separate register for heating and cooling energy. They are fitted with an M-Bus interface for integration into M-Bus networks.
    Wireless Digital Energy Meter with RS485 digital heat meter RC82 ultrasonic heating Features
    1. Internal 3.6V lithium battery power supplying;
    2. Support optical interface, RS485 interface and M-Bus interface etc. multi-communication mode, easy for centralized data management by user.
    3. Support supply water and backwater pipeline position installation to satisfy users different requirements.(Default installation: supply water position.
    4. Support level and vertical installation to satisfy users' different requirements.
    5. Calculator case's unique design, users can meet multi-angle data is read;
    6. NOWA-testing in the parallel mode is applicable.

    Technical Parameter-Profile


    ApplicationHeating/cooling/heating-cooling metering
    ApprovalMID
    Mount positionVertical or horizontal
    Calculator protection classIP 65
    Battery supply3.6V lithium battery up to 11 years lifetime
    Temperature sensor typePT1000
    Cable length of temperature sensor1.5 meter (or customized)
    Test possibilitiesdisplay, instruction (compatible with NOWA software)
    Calculator basic features
    Environmental classEN1434/MID E1+M1
    Ambient operating temperatureA Class (5~55) ℃ or B Class(-25 ~ +55) ℃ optional
    Ambient storage temperature-20~ +70 ℃
    Protection classIP 65
    Radio systemWireless M-bus can be integrated by 868,434,169MHz (OMS)
    Standard interfaceOptical interface
    Interfaces optional1 Slots for modules with M-Bus, RS485, Pulse Output
    Temperature range heating4~95℃
    Temperature range cooling4~95℃
    Extensive data memory720 days flow data and heat data
    RS485 communicationred is vcc(5~24VDC),white is B,green is A,black is GND
    Pulse outputred is output and black is GND

    Display


    Display indicationLCD, 8 digits
    UnitsMWh - kWh - GJ - Gcal - ℃ –K - m³ - m³/h
    Total values99,999,999 - 9,999,999.9 - 999,999.99 - 99,999.999
    Values displayedEnergy /Power/Volume/ Flow Rate/Temperature and more

    Interfaces


    OpticalBand rate 2400
    M-BusBand rate 300-9600
    RS485Band rate 300-9600
    Pulse outputOne pulse output

    Temperature input


    Starting temperature difference ΔΘ K0.25
    Min. temperature difference ΔΘmin K3 (2K can be customized)
    Max. temperature difference ΔΘmax K60 (105 can be customized)
    Absolute Temperature measuring range Θ ℃4 ~95 (4-130 can be customized)

    Screw thread connection version


    Bi - Directional Ultrasonic Hot Water Flow Meter With RS485 Steady Operation
    Nominal flow rateqpm3/h0.611.52.53.56610
    Nominal diameterDNmm2020202025253240
    Overall LengthLmm190190190190260260260300
    Length of calculatorL1mm150150150150150150150150
    HeightHmm47.547.547.547.552.552.562.570
    Height1H1mm103103103103106106109109
    Calculator HeightH2mm6060606060606060
    Calculator widthBmm105105105105105105105105
    Flange dimensionFmm95959595105105125140
    Flange diameterD1mm105105105105115115140150
    Hole circle diameterD2mm757575758585100110
    Screw hole diameterD3mm1414141414141818
    Number of screw holespcs44444444
    Max working pressureMPa2.52.52.52.52.52.52.52.5

    Packing & Delivery


    Packing


    With years of export experience along with excellent quality, advanced services and competitive prices, Lanry has won numerous customers' trust and support. With years of export experience along with excellent quality, advanced services and competitive prices, Lanry has won numerous customers' trust and support.

    Bi - Directional Ultrasonic Hot Water Flow Meter With RS485 Steady OperationBi - Directional Ultrasonic Hot Water Flow Meter With RS485 Steady OperationBi - Directional Ultrasonic Hot Water Flow Meter With RS485 Steady Operation

    Delivery


    Standard meter: 3-7 days

    Special meter: pls contact us

    Express, by air, by sea can be optional.
