Acoustic Doppler Ultrasonic flow meter DF6100-EI of insertion
series
Acoustic Doppler Ultrasonic flow meter DF6100-EI of insertion
series is used to measure Drainage, Mining recirculation Raw sewage, Activated sludge, Ground water, Pulp and paper
slurries, Chemical slurries,and so on.
Advanced technique allows this instrument to operate with high
reliability and low maintenance.
Insertion transducers permit the instrument to be installed without
interrupting system pressure or flow.
DF6100-EI Series Doppler Insertion Ultrasonic Flow Meter can
measure metal or plastic pipes with a certain amount of air bubbles
or suspended solids.
Acoustic Doppler Ultrasonic flow meter DF6100-EI of insertion
series Feartures:
1. Excellent quality, elegant shape, convenient to use and economy
are its biggest strong points of it.
2. Accuracy: 2.0% Calibrated span
3. Excellent low flow rate measurement ability, low to 0.05m/s
4. User-friendly configuration
5. It is suitable for pipe sizes ranging from 65 to 4000mm
6. Do not need to shut down the pipe flow when installing the
transducers
Technical Parameters:
Specifications: Transmitter
| Measurement principle | Doppler ultrasonic |
| Resolution | 0.25mm/s |
| Repeatability | 0.2% of reading |
| Accuracy | 0.5% -- 2.0% F.S. |
| Response time | 2-60s for optional |
| Flow Velocity Range | 0.05- 12 m/s |
| Liquid Types Supported | Liquids containing 100ppm of reflectors and at least 20% of the
reflectors are larger than 100 micron. |
| Operating temperature | -20℃ to +60℃ |
| Housing material | Fiberglass |
| Measurement Channels | 1 |
| Totalized | gallons, ft³, barrels, lbs, liters, m³,kg |
| keypad | 4pcs buttons |
Specifications: Transducer
| Transducers Type | Insertion type |
| Degree of protection | IP67/ IP68 |
| Suited Liquid Temperature | Std. Temp.: -35℃~85℃ |
| High Temp.: -35℃~150℃ |
| Pipe diameter range | 65-4000 mm |
| Cable Length | Std: 10m |
| Material of transducer heads | Stainless steel |
| Transducer Size | 58*58*295mm |
